10 m3/Day MBR Wastewater Treatment Equipment
The parameters of this MBR System:
Average Capacity: 10m3/Day
Material of Container: Carbon Steel + Anti-corrosion Painting; 5mm thickness of the Carbon Steel.
Dimension:1.5×2.0×4.0m <W*H* L>
Power Consumption :2.5KW/H
Controlling: Automatic Running
Output Water Quality: Meet the international standards, for discharge or reuse in irrigation.
Containerized MBR System are designed for sewage treatment, and industrial wastewater treatment for different application such as for industry (food industry) or hotel, for remote communities without access to a municipal sewage system, but also to improve existing treatment plants.
For more information or quotation, please share those information for us:
1. Raw water qaulity test report ?
2. Output Water quality standard?
3. Treatment Capacity per hour ?
Containerized MBR System treatment process:
10 m3/Day Containered MBR System main parts Included:
The Standard components for the mobile containerized MBR System
MBR Modular Compact Tank ( Carbon steel + Coating ) Control Panel
FRQ
1). How does Hinada’s MBR system work?
Wastewater passes through pre-treatment, equalization, anaerobic/anoxic/aerobic biological tanks, and an MBR membrane tank. Microorganisms remove organic matter and nutrients, while membranes separate clean water from sludge, bacteria, and suspended solids.
2). What capacity can Hinada provide?
Typical containerized units range from 10 m³/day to 200 m³/day. Larger flows can be handled by multiple containers or custom-designed systems.
3) What types of wastewater can it treat?
Domestic sewage, municipal wastewater, hotels, resorts, hospitals, food processing, car wash, surface treatment, industrial wastewater, and remote-site wastewater. Industrial streams may require additional pre-treatment.
4) How long do MBR membranes last?
Normally 3–5 years with proper operation, cleaning, and pre-treatment. Actual life depends on wastewater characteristics and maintenance.
5) Is the system automatic?
Yes. Hinada MBR systems use PLC control with HMI, automatic backwashing, dosing, alarms, and optional remote monitoring via SCADA or 4G.
6) Is the system automatic?
Yes. Hinada MBR systems use PLC control with HMI, automatic backwashing, dosing, alarms, and optional remote monitoring via SCADA or 4G.
7) What are the limitations?
- Higher capital and operating cost than simple treatment systems
- Membrane fouling requires proper control
- Pre-treatment is important
- Skilled maintenance is recommended
Applications of MBR System
- Municipal & Domestic Sewage: Remote communities, islands, and residential complexes without access to municipal sewer networks.
- Hotels & Resorts: Effective treatment despite variable seasonal flows.
- Industrial Wastewater: Food processing, car wash, surface metal treatment, and other industrial effluents.
- Temporary & Remote Sites: Refugee camps, military camps, construction sites, and offshore platforms
The advantages of mobile MBR wastewater plant:
- Cost savings, it’s especially for small capacity project.
- Moveable and Less Constructuion works
- High Quality, Assembly it according to ISO standard and with quality parts
- Fully automatic, easy operation and management
- Everything from one source provider
- Customerized wastewater treatment plant, according to your project requirement.
The Benifits of Containerized MBR Plant:
* System operates at a low pressure
* Removes bacteria and viruses
* Keeps essential minerals in water
* Installs quickly and easily
* Does not generate waste water
* An ultrafiltration system is eco-friendly. Ultrafiltration has a 90-95% recovery rate and can be used to treat wastewater for reuse. Using a home ultrafiltration water system benefits the environment by reducing the amount of plastic water bottles discarded in landfills.
Package
The Containered Wastewater Equipment MBR will be packaged in container or plywood case.
Our Service
1. We are the manufacturer of MBR Membrane, MBR System for waste water treatment, we can produce the products according to your requirements.
2. We Provides a full range of services , even small sewage treatment plant and water treatment equipment, sewage treatment plant from the design proposal, producing to installation and testing, even after sale. We regard our customer as a long term business partner.
3. Equipment and project sample as your reference.
- Description:
-
Containerized MBR System are designed for sewage treatment, and industrial wastewater treatment for different application such as for industry (food industry) or hotel, for remote communities without access to a municipal sewage system, but also to improve existing treatment plants.
For more information or quotation, please share those information for us:
1. Raw water qaulity test report ?
2. Output Water quality standard?
3. Treatment Capacity per hour ?Containerized MBR System treatment process:
10 m3/Day Containered MBR System main parts Included:
The Standard components for the mobile containerized MBR System
MBR Modular Compact Tank ( Carbon steel + Coating ) Control Panel
FRQ
1). How does Hinada’s MBR system work?
Wastewater passes through pre-treatment, equalization, anaerobic/anoxic/aerobic biological tanks, and an MBR membrane tank. Microorganisms remove organic matter and nutrients, while membranes separate clean water from sludge, bacteria, and suspended solids.2). What capacity can Hinada provide?
Typical containerized units range from 10 m³/day to 200 m³/day. Larger flows can be handled by multiple containers or custom-designed systems.3) What types of wastewater can it treat?
Domestic sewage, municipal wastewater, hotels, resorts, hospitals, food processing, car wash, surface treatment, industrial wastewater, and remote-site wastewater. Industrial streams may require additional pre-treatment.4) How long do MBR membranes last?
Normally 3–5 years with proper operation, cleaning, and pre-treatment. Actual life depends on wastewater characteristics and maintenance.5) Is the system automatic?
Yes. Hinada MBR systems use PLC control with HMI, automatic backwashing, dosing, alarms, and optional remote monitoring via SCADA or 4G.6) Is the system automatic?
Yes. Hinada MBR systems use PLC control with HMI, automatic backwashing, dosing, alarms, and optional remote monitoring via SCADA or 4G.7) What are the limitations?
- Higher capital and operating cost than simple treatment systems
- Membrane fouling requires proper control
- Pre-treatment is important
- Skilled maintenance is recommended
- Application
-
Applications of MBR System
- Municipal & Domestic Sewage: Remote communities, islands, and residential complexes without access to municipal sewer networks.
- Hotels & Resorts: Effective treatment despite variable seasonal flows.
- Industrial Wastewater: Food processing, car wash, surface metal treatment, and other industrial effluents.
- Temporary & Remote Sites: Refugee camps, military camps, construction sites, and offshore platforms
- Benefits
-
The advantages of mobile MBR wastewater plant:
- Cost savings, it’s especially for small capacity project.
- Moveable and Less Constructuion works
- High Quality, Assembly it according to ISO standard and with quality parts
- Fully automatic, easy operation and management
- Everything from one source provider
- Customerized wastewater treatment plant, according to your project requirement.
The Benifits of Containerized MBR Plant:
* System operates at a low pressure
* Removes bacteria and viruses
* Keeps essential minerals in water
* Installs quickly and easily
* Does not generate waste water
* An ultrafiltration system is eco-friendly. Ultrafiltration has a 90-95% recovery rate and can be used to treat wastewater for reuse. Using a home ultrafiltration water system benefits the environment by reducing the amount of plastic water bottles discarded in landfills. - Package
-
Package
The Containered Wastewater Equipment MBR will be packaged in container or plywood case.
- Our Service
-
Our Service
1. We are the manufacturer of MBR Membrane, MBR System for waste water treatment, we can produce the products according to your requirements.
2. We Provides a full range of services , even small sewage treatment plant and water treatment equipment, sewage treatment plant from the design proposal, producing to installation and testing, even after sale. We regard our customer as a long term business partner.
3. Equipment and project sample as your reference.
