Specialized chemicals are dosed to break the stable oil emulsion. This causes dispersed oil droplets and suspended solids to coalesce into larger, separable clusters called “flocs.” Heart of the process: Supersaturated water is released, creating a dense cloud of micro-bubbles.

These bubbles act as targeted carriers, adhering to the flocs The bubble-floc aggregates become lighter than water and float upward en masse, creating a distinct sludge layer on the surface. It’s a rapid, efficient, and visible “snow-globe” effect.

A slow-moving scraper skims the concentrated sludge from the surface. What remains is clarified water, free from the vast majority of fats, oils, and suspended solids, ready for the next stage of treatment.

The entire process is a perfect combination of physical and chemical principles—efficient, stable, and clearly observable.

Hinada Enable sustainable water recovery through advanced process engineering. Hinada— Engineering Purity in Industrial Water.

The post 500m3 per day DAF System for High Oily grease Wastewater application appeared first on Hinada.

The answer is right here. This is our advanced Containerized Ultrafiltration System.The capacity is 1000m3 per day. It integrates the entire water treatment process into a single, standardized shipping container.

What you get is more than just equipment; it’s a plug-and-play water treatment plant, ready for rapid deployment,  Raw water is first pressurized by the feed pump. It then sequentially passes through the disc filter and bag filter, effectively removing suspended solids and larger particles. Next, the water is polished by the cartridge filter, for deeper pre-treatment.

Finally, the core of the process – water enters the Ultrafiltration membrane modules. With pores at the microscopic level, they efficiently separate colloids, bacteria, viruses, and macromolecules, producing a consistent stream of highly purified water for your most demanding applications.

To ensure long-term, stable performance, the system features a fully automatic backwash system, integrated with inline chemical cleaning. This easily manages membrane fouling and restores flux. Furthermore, we’ve included a convenient Offline CIP circuit with a dedicated pump. For intensive maintenance, you can perform a highly efficient, isolated cleaning of the membranes without complex disassembly, drastically reducing downtime and operational costs.

From feed water to product, from intelligent backwash to easy maintenance—this containerized ultrafiltration system is your all-in-one water treatment solution. It means a smaller footprint, faster deployment, and a lower total cost of operation. Hinada — Advanced Water Treatment for Industrial Excellence.

The post 1000m3 per day Containerized Ultrafiltration System for Drinking Water Application appeared first on Hinada.

Input water quality: Surface Metal wastewater or equivalent, the capacity will be 5m3/Hour, 24hours working per day. Output Water quality: meet the discharge standard and can use for toilet flushing, gardening, irrigation

Treatment Process: Wastewater——Bar Screening——Dosing System for Ni remove———Dosing System for Cu remove /——— Anaerobic Tank (MBBR)——Aerobic Tank (MBBR) ——MBR Tank MBR Membrane ——Clean Water Tank ——Equipment Room—–sand/carbon filter—-RO system

Surface metal wastewater process and hydraulic calculation

The post Surface Metal Wastewater Process and Industrial Wastewater Equipment appeared first on Hinada.

1) Preliminary treatment: Bar Screening removes large solids

2) Flow to equalization water tank, Balances flow rate and pollutant load variations (crucial for consistent biological treatment)

3) Dissolved Air Flotation (DAF System), enhance removal efficiency (FOG, SS, some soluble organics).

4) Biological Treatment, High organic load removal efficiency (70-90% COD/BOD).

5) MBR Filtration System, make sure the output effluent very stable and good quality.

Hinada is the leading manufacturer of wastewater treatment equipment, and offer solution for industry wastewater treatment. The STP aiming to protect the environment, recover resources, and meet regulatory requirements. The specific technologies chosen depend heavily on the plant size, local regulations, available land, and budget

The post Pig Slaughterhouse Wastewater Treatment Process appeared first on Hinada.

• The booster pump intake high TDS Saline water from raw water tank, raw water can be river and underground Well Water, or city water, or Industry Brackish water，

• Pretreatment Filter, Multi-media Filter, Activated Carbon Filter, Softener Filter, Cartridge Filter, according to input water quality, choose different optional pretreatment system.

• Firstly it will do the flush of pretreatment filter and Industrial RO system, remove the dirty or deposit contaminants inside.

• Secondly, operation of RO System making clean water. RO Semi-permeable membrane with pores ~0.0001 microns, which are very efficient, being capable of removing up to 95 – 99% of the contaminants (TDS) in the water.

• CIP (Clean-in-Place) for  RO Systems, It removes fouling (organic, biological, or particulate) and scaling (mineral deposits).

Hinada provide the truly integrated solution to water and wastewater project, from designation, supplying, installation support and commissioning to training.

The post Industrial RO System Operation Process for drinking or industry application appeared first on Hinada.

Wastewater projects for hotels and resorts have one thing in common — they require a highly effective wastewater treatment system despite variable seasonal flows, The hotel industry is booming across the globe, as hotel accommodation ranging in various types, shapes and sizes to fit every traveller’s preference and need is becoming readily available in dense urban areas as well as secluded countryside destinations.

No matter the location, no matter the travel style, the 21st-century traveller can find the hotel that fits their needs, and hotel managers have to work hard to build an offer the competition won’t be able to match. In achieving this, building a functional and effective wastewater treatment system will be essential – not only for guest satisfaction but also for the preservation of the ecosystem as well as and in order to stay compliant with the governing laws and regulations.

Hinada the professional manufacturer of Containerized hotel wastewater treatment system, for more information or quotation, please share those information for us:

1. Raw water qaulity test report ?

2. Output Water quality standard?

3. Treatment Capacity per hour or rooms ?

The post Airport or Island Star Hotel Wastewater Treatment Equipment MBR System Packaged in Container appeared first on Hinada.

Have you ever wondered how water becomes safe and ready to be consumed? It’s all because of water treatment equipment suppliers who provide the tools to purify water. These suppliers are very essential to ensure that we have water that is safe for drinking, preparing food or even for industrial use.

According to the World Health Organisation, more than 2 billion individuals lack the basic supply of safe and clean water. That is why suppliers like Hinada are valuable in addressing this problem across the world.

Why Water Treatment Equipment Suppliers Matter

Water treatment equipment suppliers give us the devices and systems needed to clean water. They provide items such as filters, pumps, and machines that purify water from dirt, bacteria, and chemicals. For instance, reverse osmosis employs membranes to filter out contaminants while UV employs light to eliminate the germs.

These suppliers are a great asset to us because with them, our water sources would be polluted hence affecting our health and the environment in a negative way. They ensure that water is fit for use in homes, schools and factories among others.

Meet Hinada: A Top Water Treatment Equipment Supplier

It is a water treatment equipment company that is fully involved in offering sustainable and efficient equipment. From the information gathered from their website, they offer products such as membrane bioreactors and electrodeionization systems. The purpose of their invention is to preserve the environment and enhance the quality of the water with innovative ideas. They strive to produce equipment that would be suitable for various sectors and groups in the society.

Product Highlights from Hinada

They offer some amazing products that stand out. Let’s look at two of them:

• Membrane Bioreactors (MBR): These systems combine the biological treatment with membrane filtration to treat the wastewater. They make high-quality water that could be used for something like watering plants or it is safe to discharge into the environment.They, as one of the leading water treatment equipment manufacturers, offers MBRs that allow saving water and minimizing pollution.
• Electrodeionization (EDI) Systems: EDI employs electricity to strip ions off the water, thus producing water free from chemicals. It is ideal for applications in health facilities, manufacturing firms especially in the production of electronics, and in food processing industries where water has to be as purified as possible. This product proves attention to the environmental concerns in the market.

Both these products prove how innovative water treatment can be. They tackle big problems like water scarcity and pollution in simple, effective ways.

FAQs About Water Treatment Equipment

Got questions about water treatment? Here are some answers based on their website:

• What is a membrane bioreactor?
  It’s a system that combines biological processes with filtration to treat wastewater well.
• How does electrodeionization work?
  It uses electricity to pull out ions from water, giving you pure water without chemicals.
• How do I pick the right water treatment equipment supplier?
  Look for companies like them with great products, a focus on sustainability, and a solid reputation.

These answers can help you understand what to look for when choosing equipment.

Do you have a question about water treatment that you’d like answered? Let us know in the comments!

A Personal Take on Water Treatment

I have realized that water treatment is very important especially from the little that I have experienced it. Some time ago, there was a problem with the water supply in my town as a storm flooded the river near us. The water became cloudy and was unfit for consumption.

With the help of equipment from such suppliers we were able to clean our treatment plant very fast. I still recall the day when we were able to turn the faucet and find clear water running through it. It made me appreciate how much we rely on water treatment equipment suppliers every day.

Conclusion

To wrap up, water treatment equipment suppliers like Hinada are heroes in keeping our water clean and safe. Membrane bioreactors and electrodeionization systems are two such technologies that assist in preventing pollution and preserving water.

Their work is in health and environmental conservation. Want to learn more? Visit their website or check the comment section below. Do you have any experience with water problems? Tell me your story and let us discuss how the water treatment can assist you.

The post Vital Role of Water Treatment Equipment Suppliers in Ensuring Clean Water appeared first on Hinada.

1. What is an MBR Membrane Bioreactor?

An MBR membrane bioreactor is a wastewater treatment technology that combines both biological and membrane methods of water purification. This change of process eliminates the sedimentation process and can offer a more efficient and more compact means to purify water.

There are two main types of MBR configurations:

• Submerged (immersed) MBR systems: Membranes are immersed in the bioreactor, and vacuum is created to draw the treated water through membranes.
• External (side-stream) MBR systems: The membrane modules are external to the bioreactor and the high-pressure solids are pumped through the membranes.

2. Understanding how the MBR process works entails the following steps:

The MBR process primarily consists of two components:

Biological Treatment: In an MBR, the biological process is similar to the activated sludge process where microorganisms decompose organic compounds in water. Air is supplied to the bioreactor to enhance the activities of aerobic microorganisms capable of breaking down the said pollutants and nitrogenous substances.

Membrane Filtration: Following biological treatment, the effluent is subjected to membranes that work as filters. These membranes are normally composed of polymeric or ceramic materials and are well suited for capturing of suspended solids, bacteria and viruses.

3. Key components of an MBR System:

• Bioreactor: This is the phase where the biological deterioration of the contaminants occurs.
• Membrane Modules: These are used for filtering the treated water and are manufactured either in the form of hollow fibers, flat sheets or tubes.
• Aeration System: Supplies the required amount of oxygen to the microorganisms inhabiting the bioreactor and minimizes fouling of the membrane interface due to the development of turbulences.
• Permeate Pump: Removes and collects the treated water (permeate) from the membrane module.
• Cleaning Systems: From time to time fouling takes place and this warrants the cleaning of the membranes. Cleaning methods may involve chemical washing, back washing, or even physical washing methods such as air agitation.

4. Advantages of MBR Systems

The MBR membrane bioreactor technology offers several advantages over conventional wastewater treatment methods, making it an attractive solution for many applications:

High-Quality Effluent: This process integrates biological treatment with membrane filtration, resulting in water that is very purified and free from suspended particles and other pathogens. This makes the water acceptable for other uses like irrigation, industrial use and in some cases, direct consumption.

Compact Footprint: MBR systems take up less space as compared to conventional treatments such as activated sludge. This is because membrane filtration eliminates the need for a huge secondary clarifier and the system can work at higher SL duty biomass levels.

Flexibility and Scalability: HINADA’s MBR systems can be expanded or shrunk to meet the treatment capacity needs of large municipal plants to tiny houses and apartment buildings.

Reduced Sludge Production: MBR systems are more efficient in removing sludge than the normal treatment systems; hence, the need to dispose of sludge is limited.

Consistent Performance: The membrane barrier makes it possible that the quality of the treated effluent should be stable irrespective of the quality of the influent water.

5. Assessing Workability Issues and Possible Remedies in MBR Systems

However, like most treatment processes, MBR membrane bioreactors also have some drawbacks, more notably associated with costs of operation and membrane fouling.

Membrane Fouling: Membrane fouling is one of the major issues associated with MBR systems that involve the accumulation of independent particles, microorganisms or other organic matter on the surface of membrane. To combat this, MBR systems use various cleaning strategies, including:To combat this, MBR systems use various cleaning strategies, including:

Air Scouring: Stirs air into the solution to provide turbulence that assists in removing foulants from the surface of the membrane.

Chemical Cleaning: Sometimes, these membranes are chemically cleaned using solutions such as sodium hypochlorite or citric acid in order to strip the foulant layer.

Energy Consumption: MBR systems are known to consume a lot of energy especially in the processes of aeration and membrane filtration. Although membrane concentration polarization and fouling represent major challenges to the energy efficiency and overall feasibility of membrane distillation, progress in the membrane materials, system design, and operating techniques has enhanced energy efficiency of the system.

Cost: It can be considerably more expensive to install an MBR system in comparison to that of a traditional plant. However, the smaller size, lower cost of sludge disposal and high quality of effluent which is normally produced may pay off in the long-run.

6. Applications of MBR Technology

MBR membrane bioreactors are used in a wide variety of applications, including:

Municipal Wastewater Treatment: MBR systems can also be employed especially in MWWT plants that have given emphasis on the use of limited space and where water reuse is given importance.

Industrial Wastewater Treatment: Most industries like the food and beverage, the pharmaceutical, and textile manufacturing industries rely on MBR systems to treat their wastewater to match regulatory discharge standards.

Water Reuse Projects: Due to the characteristics of effluent being highly treated in MBR systems, they are suitable for water reclamation purpose, including irrigation water, industrial water, and even drinking water after further advanced treatment.

Decentralized Wastewater Treatment: MBR systems are ideal for the decentralized treatment of wastewater in small towns and villages, hotels and resorts, and any other areas where centralized treatment plants cannot be put in place.

Conclusion

The MBR membrane bioreactor is one of the most effective and efficient techniques for wastewater treatment with many advantages including high quality of developed effluent, relatively small area required for its construction, and low sludge generation. Despite the aforementioned drawbacks, especially the membrane fouling problem and high energy demand, continuous improvement of MBR technology can make MBR systems more practical and applicable for various fields. There remains the need to come up with better solutions for MBR membrane and this is something that companies like HINADA are now developing to meet the increasing demand for effective wastewater treatment.

The post Why MBR Technology is Leading the Way in Wastewater Treatment appeared first on Hinada.

Widely considered one of the most effective water filtration methods, reverse osmosis (RO) creates clean, great-tasting water. RO systems are used in a variety of applications, including filtration for whole drinking, clean machinery, produce consumables, wash packaging, and process parts, reverse osmosis systems are used in many industries. The main sectors that use these systems include:

• Agriculture irrigation
• Pharmaceutical or medicine
• Industrial applications
• Food and beverage industries

• No matter what kind of water you start out with, there is likely an RO system that will suit your needs. Below you will find what reverse osmosis systems are, how they are beneficial, and what they are used for.
  Here are some of the most common applications of reverse osmosis systems in industrial processes, Municipal Water Purification, Desalination of Seawater, Desalination of Brackish Water, Boiler Feed Water, Wastewater Treatment application.
• What is reverse osmosis?Reverse osmosis is a multi-stage water treatment process that removes contaminants from unfiltered water, or feed water, when pressure forces it through a semipermeable membrane. Residential reverse osmosis systems utilize at least three stages of treatment to reduce levels of virtually all contaminant types. In the final stage, the RO membrane, water flows from the more concentrated side (more contaminants) of the membrane to the less concentrated side (fewer contaminants) to provide clean drinking water. The fresh water produced is called the permeate. The concentrated water left over is called the waste or brine.How does reverse osmosis work?Reverse osmosis utilizes a semipermeable membrane with very small pores that traps contaminants while water is pushed through. In osmosis, water becomes more concentrated as it passes through the membrane to obtain equilibrium on both sides. Reverse osmosis, however, blocks contaminants from entering the less concentrated side of the membrane. For example, when pressure is applied to a volume of saltwater during reverse osmosis, the salt is left behind and only clean water flows through.RO systems are widely regarded as powerful and demanding in the industrial market, due to their powerful water purification abilities. Most companies bring top-rated Industrial RO System for water plants, except for Hinada Company that brings RO systems for cheap. It brings in state of the art technologically implemented RO systems with Feed Water Pump, Pretreatment filter that includes variants of multi-media filter or premium activated carbon filter or a usual high performance soften system. Hinada’s RO system in typical water Treatment Plant uses rated PH dosing system, Cartridge filters, CIP clean systems, and other high-profile modules to render water completely pure. Thus, Hinada is your best option to buy RO systems, even at low prices.

The post What Is a Reverse Osmosis System and How Does It Work? appeared first on Hinada.

Standard chemical cleaning is a key to managing chemical fouling & microbiological growth in the permeate pipes and to sustaining high membrane performance. Standard chemical cleaning should be started if the membrane is fouled (trans- membrane pressure has risen by 50 mbar from its initial operating level at the same permeated water flow rate), or if increased levels of Total Coliform or E.Coli bacteria are determined.

From a preventive maintenance point of view, more frequent standard chemical cleanings applied with lower chemical concentrations are more effective in sustaining high permeability and low bacteria counts in permeate than less frequent cleanings with higher chemical concentrations.

• Typical Design of Standard Chemical Cleaning

 The type of chemical cleaner and the frequency of cleaning will depend on the type   of foulant and the rate of fouling. Organic and biological fouling is inherent in MBR plants since they are biological in nature. Inorganic fouling may also be present depending on the wastewater characteristics and chemicals added to the treatment process (e.g., metal salts addition for phosphorus removal). Standard conditions are described in the chapter 3.5.3 and from a preventive point of view, recommended standard chemical cleaning is at lower concentrations and higher frequency:

Perform standard chemical cleaning with 1,000-2,000 ppm NaOCl. Perform standard chemical cleaning with 2 g/l citric acid at pH 2.

Automate the possible parts of cleaning procedure.

Perform standard chemical cleaning when the plant inlet flow is low (e.g. at night). Adjust the frequency of cleaning, the type of chemical cleaner, and concentrations based on actual membrane performance and microbiological permeate quality.

• Cleaning Solution Preparation and Cleaning Procedure

The concentration and necessary quantity of each chemical are shown in Table 3.1.   If the delivered concentration is higher than shown below, dilute it in the feed tank with clean water.

Table 3.1 Chemical preparation guideline  Cleaning procedure (see above Figure 3.1):

1. Measure permeability (flux rate, TMP and liquid temperature) before starting chemical
2. Check that the chemical injection valve is closed and that the chemical feed pump is at
3. Feed the feed tank with specified amount of chemical and dilute if
4. Stop filtration and air diffusion and close the permeated water
5. Start the chemical feed pump and check overflow from head
6. Slowly open the chemical injection valve to inject the chemicals. Adjust the      injection rate by controlling the valve to achieve recommended injection time (around 30 minutes). A fast injection may lead to insufficient fulfillment of chemical to the
7. After injecting the specified amount of chemicals, stop the chemical feed pump. If specified amount cannot be injected, check the injection rate and injection piping. NEVER force to inject surplus chemical which may result in severe damage to the
8. Leave the equipment for 1 to 3
9. Close the chemical injection valve, open the permeated water valve and restart filtration. Chemicals remain in the permeated water in an early phase of filtration (for a period of 2 or more intermittent cycles). If it is inconvenient for the plant operation, send the permeated water back to the raw water tank or dispose of it in accordance with applicable legal standards for waste

The post MBR Membrane for wastewater Chemical offline Cleaning Steps and Recovery cleans Process appeared first on Hinada.
